ACiQ Essentials Economy 11.5k R-32 208/230V Mini-Split
The 230V take on the Economy 12k, this R-32 unit shares the tier's 17 SEER2 and 9.5 EER2 but drops to an 8.5 HSPF2. Heating runs 11,500 BTU at 47F, 8,100 BTU at 17F, and 7,000 BTU at 5F. It's a bare-bones one-ton zone for buyers who have a 230V circuit and want to spend as little as possible.
1 zoneProfessional installCurrent
Refrigerant generation
R-32 - current-generation refrigerant
Paid link
$565 / Fresh price - checked Jul 26, 2026
Need this installed?
Get installation quotes
Image: HVACDirect
Data completeness: 85%
- Last sourced
- Jul 26, 2026
SplitAtlas score
7.3 / 10
Cooling efficiencyBottom quartile
(17.0 SEER2) among 12k systems
Heating efficiencyBottom quartile
(8.5 HSPF2) among 12k systems
Cold-weather performanceBottom quartile
(60.9% heat retained at 5F; 5 F heating floor) among 12k systems
WarrantyBottom quartile
(4 yr parts / 6 yr compressor) across the catalogue
Feature setBelow average
(3 verified features) across the catalogue
Price-to-performanceTop 10%
($565 median retail) among 12k systems
Documentation & partsBelow average
(6 manuals; spec sheet) across the catalogue
Not evaluated
- Installation accessibility — not applicable (professional install)N/A
professional install - DIY-accessibility not applicable
Key ratings
Buyer review snapshot
Best for / skip if
Skip if
- Top-efficiency cooling is the priority; SEER2 is 17.
Install difficulty
Professional install
- Electrical: 230V; MCA 11 A; breaker/fuse 15 A.
- Line set: connection type not sourced; precharged 16 ft; included 16 ft.
Alternatives
- Daikin ATMOSPHERA 12,000 BTU R-32 208/230V (FTXM12WVJU9 / RXM12WVJU9)
9.0 score / 12k / SEER2 25.2 / -13 F heating floor / 208/230V
Exact destination at HVACDirect: $2,848.00, checked Jul 23, 2026
- Blueridge XS6 Max Efficiency 12,000 BTU R-454B 208/230V (BXS6A12WM0 / BXS6A12UC0)
8.9 score / 12k / SEER2 29.4 / -22 F heating floor / 230V
Exact destination at Alpine Home Air: $1,979.00, checked Jul 24, 2026
- Senville ELITE 12,000 BTU R-454B 208/230V (SENE-12EL-IHH / SENE-12EL-OH)
8.9 score / 12k / SEER2 29.4 / -22 F heating floor / 187-253V
Exact destination at Senville: $1,699.99, checked Jul 24, 2026
Availability and price context
- Verified current price: $564.99 at HVACDirect; availability in_stock; checked Jul 26, 2026.
Source date
- Model data sourced
- Jul 26, 2026
- Page reviewed
- Jul 26, 2026
- Source-backed records
- 3
- Newest source retrieved
- Jul 26, 2026
Warranty tiers
Warranty: 4 years parts and 6 years compressor as standard.
Strengths
- Among the least expensive one-ton options ACiQ sells, with full R-32 low-GWP refrigerant.
- Straightforward direct purchase from HVACDirect keeps the cost of ownership predictable.
Weaknesses
- HSPF2 of 8.5 and a taper to 7,000 BTU at 5F make it a weak choice for cold winters.
- No ENERGY STAR certification, and the value-brand network offers less local support than premium names.
Climate suitability
- Minimum heating ambient
- 5 F[1]
- Rated heating at 5F
- 7,000 BTU/h[2]
- Rated heating at 17F
- 8,100 BTU/h[2]
- Rated heating at 47F
- 11,500 BTU/h[2]
Specifications
ShowHide
- Manufacturer
- ACiQ
- Brand
- ACiQ
- Product line
- ACiQ Essentials Economy
- Model number
- ACIQ-KE12W-W-HP230B indoor / ACIQ-KE12Z-HP230B outdoor
- Indoor unit model
- ACIQ-KE12W-W-HP230B
- Outdoor unit model
- ACIQ-KE12Z-HP230B
- Number of zones
- 1
- Max indoor units
- not published
- Rated cooling capacity
- 11,500 BTU/h[2]
- Rated heating capacity
- 11,500 BTU/h[2]
- Voltage
- 230 V[1]
- MCA
- 11 A[1]
- Maximum fuse or breaker size
- 15 A[1]
- Breaker needed
- not published
- SEER2
- 17 SEER2[2]
- EER2
- 9.5 EER2[2]
- HSPF2 (Region 4)
- 8.5 HSPF2[2]
- HSPF2 (Region 5)
- not published
- COP
- not published
- COP at 47F
- not published
- COP at 5F
- 1.75 COP[2]
- Minimum outdoor heating temperature
- 5 F[1]
- Minimum outdoor cooling temperature
- 54 F[1]
- Maximum outdoor temperature
- 122 F[1]
- Indoor noise range
- not published
- Outdoor noise rating
- 55 dBA[1]
- Indoor weight
- not published
- Outdoor weight
- 61.73 lb[1]
- Refrigerant
- R-32[2]
- Refrigerant charge
- 41.6 oz[1]
- Manufacturer coverage
- not published
- Line-set size
- 1/4 in liquid / 3/8 in suction
- Included line-set length
- 16 ft[1]
- Maximum line-set length
- not published
- Max line set per indoor
- not published
- Maximum elevation difference
- not published
- Max height between indoor units
- not published
- Wi-Fi support
- supported[1]
- Energy Star status
- Not ENERGY STAR certified[3]
- AHRI certification number
- 218045390[2]
- Warranty
- Standard: 4 yr parts / 6 yr compressor (published per-line terms with online registration). 6-year compressor / 4-year parts with online registration
- Install path
- Professional install
- Retail price
- $564.99
- Available retailers
- HVACDirect
- Manual links
- AHRI public directory record 218045390, ENERGY STAR exact check 218045390, 12,000 BTU ACiQ Essentials 17 SEER2 Single Zone Wall Mount Mini Split Heat Pump System - R32 | 230V HVACDirect installation resources listing, 12,000 BTU ACiQ Essentials 17 SEER2 Single Zone Wall Mount Mini Split Heat Pump System - R32 | 230V, HVACDirect exact affiliate offer aciq-essentials-economy-12k-r32-230v, 12,000 BTU ACiQ Essentials 17 SEER2 Single Zone Wall Mount Mini Split Heat Pump System - R32 | 230V HVACDirect product specification grid
- Specification sheet
- 12,000 BTU ACiQ Essentials 17 SEER2 Single Zone Wall Mount Mini Split Heat Pump System - R32 | 230V HVACDirect product specification grid
- Last sourced date
- Jul 26, 2026
Retail purchase context
Some retailer links may earn us a commission at no extra cost; paid relationships never change scores or recommendations. Affiliate disclosure
Paid link
Check price at HVACDirect
$565 / Fresh price - checked Jul 26, 2026
Installation considerations
ShowHide
- Liquid line
- 1/4 in[1]
- Suction line
- 3/8 in[1]
- Line connection type
- not published
- Precharged length
- 16 ft[1]
- Included line-set length
- 16 ft[1]
- Maximum line-set length
- not published
- Max line set per indoor
- not published
- Max height between indoor units
- not published
- Indoor dimensions
- not published
- Outdoor dimensions
- 30.98 x 19.61 x 11.42 in[1]
- Indoor weight
- not published
- Outdoor weight
- 61.73 lb[1]
- Drain size
- not published
Related systems and guides
- More ACiQ systems
- ACiQ 115 V option
- Cooper & Hunter 11.5k model
- ACiQ sibling model
- M-Series MLZ One-Way Ceiling Cassette 11.3k
- Guide library
- Mini split buying guide
- Single-zone vs multi-zone mini splits
- Troubleshooting
- ACiQ mini split review: is ACiQ any good?
- The best DIY mini splits of 2026
- What "DIY mini split" actually means
- How to install a mini split (DIY overview)
- R-32 vs R-454B: the mini split refrigerant change explained
- Mini split for a hot upstairs
- Mini splits for an ADU or tiny home
- What the symbols on your mini split remote mean
- Why mini split installation quotes vary so much
- Mini split remote not working
- Mini split Wi-Fi not connecting
- Your mini split is showing a refrigerant leak code
- Mini split outdoor unit not running
- One room won't heat or cool on a multi-zone mini split
- Line sets
- Line-set covers
Frequently asked questions
- Can I install the ACiQ Essentials Economy 11,500 BTU R-32 208/230V (ACIQ-KE12W-W-HP230B / ACIQ-KE12Z-HP230B) myself, or do I need a pro?
- ACiQ Essentials Economy 11,500 BTU R-32 208/230V (ACIQ-KE12W-W-HP230B / ACIQ-KE12Z-HP230B) is built for professional installation: the line set must be flared, evacuated, and charged, which requires EPA-certified refrigerant handling. Installing it outside the manufacturer's requirements can void the warranty, so budget for a qualified HVAC installer.
- Will the ACiQ Essentials Economy 11,500 BTU R-32 208/230V (ACIQ-KE12W-W-HP230B / ACIQ-KE12Z-HP230B) keep heating in a cold winter?
- The manufacturer publishes 7,000 BTU/h of heating output at 5F. Rated heating operation extends down to 5 F. Certified heating efficiency is 8.5 HSPF2. Match those numbers against your climate's design temperature - in cold regions, output at 5F matters far more than the nameplate capacity measured at 47F.
- What electrical circuit does the ACiQ Essentials Economy 11,500 BTU R-32 208/230V (ACIQ-KE12W-W-HP230B / ACIQ-KE12Z-HP230B) need?
- Published electrical requirements: 230 V voltage, 11 A minimum circuit ampacity, and 15 A maximum breaker or fuse sizing. Confirm the final circuit against the unit nameplate and local code with a licensed electrician.
- What warranty does the ACiQ Essentials Economy 11,500 BTU R-32 208/230V (ACIQ-KE12W-W-HP230B / ACIQ-KE12Z-HP230B) carry?
- The manufacturer publishes these warranty tiers: Standard: 4 yr parts / 6 yr compressor (published per-line terms with online registration). Registration requirements and proof of qualified installation commonly affect coverage, so read the warranty terms before install day.
Data sources
ShowHide
- HVACDirect / ACiQ: 12,000 BTU ACiQ Essentials 17 SEER2 Single Zone Wall Mount Mini Split Heat Pump System - R32 | 230VSourced - manufacturer product page
Covers Frequency, Maximum breaker size, Maximum fuse size, Minimum circuit ampacity, Phase, Voltage and more
- Air-Conditioning, Heating, and Refrigeration Institute: AHRI Appendix M1 public detail for ACIQ-KE12Z-HP230B / ACIQ-KE12W-W-HP230BSourced - AHRI directory
Covers AHRI certification number, Rated cooling capacity, COP at 5F, EER2, Rated heating capacity, HSPF2 (Region 4) and more
- ENERGY STAR: ENERGY STAR exact row check for AHRI 218045390Sourced - Energy Star listing
Covers Energy Star status
