Midea / Midea Easy Pro Extreme Heat
Midea Easy Pro Extreme Heat 15.4k R-454B 208/230V Mini-Split
The 15k is a cold-climate head with more certified heating at 5F than at 47F: 15,400 BTU at 47F, 16,600 BTU at 17F and 17,500 BTU at 5F. Efficiency is mid-pack at 22.2 SEER2, 13.5 EER2, and 11.5 HSPF2 on R-454B, but the low-temperature output is the headline. This is a unit built for a hard winter.
1 zoneProfessional installCurrent
Refrigerant generation
R-454B - current-generation refrigerant
Need this installed?
Get installation quotes
Image: Famous Supply
-ok_MAIN1.png){kind=link}
Data completeness: 100%
- Last sourced
- Jul 27, 2026
SplitAtlas score
9.2 / 10
Cooling efficiencyAbove average
(22.2 SEER2) among 18k systems
Heating efficiencyTop quartile
(11.5 HSPF2) among 18k systems
Cold-weather performanceTop quartile
(5F certified capacity: 100% of the 47F rating; -22 F heating floor) among 18k systems
WarrantyTop 10%
(12 yr parts / 12 yr compressor) across the catalogue
Feature setAbove average
(5 verified features) across the catalogue
Documentation & partsBelow average
(6 manuals; spec sheet) across the catalogue
Not evaluated
- Installation accessibility — not applicable (professional install)N/A
professional install - DIY-accessibility not applicable
- Price-to-value — not evaluatedN/A
This is a professionally installed, quote-only system, so we can't score its price. Get an installed quote to compare real cost.
Get a quote
Key ratings
Buyer review snapshot
Best for / skip if
Best for
- High-efficiency shortlists; SEER2 is 22.2.
Install difficulty
Professional install
- Electrical: 230V.
- Line set: connection type not sourced; max 213 ft.
Availability and price context
This system needs a professional install, so its real price is an installed quote that depends on your home. We don't link to a listing for this exact model; get installation quotes to price it.
Source date
- Model data sourced
- Jul 27, 2026
- Page reviewed
- Jul 27, 2026
- Source-backed records
- 4
- Newest source retrieved
- Sep 14, 2026
Warranty tiers
- Base
- 5 yr parts / 7 yr compressor - base coverage
- Registered
- 12 yr parts / 12 yr compressor - online registration at mideacomfort.us within 60 days of installation
The score uses Registered. Additional published terms are shown for reference and not counted in the score.
Model context
- Structured ratings
- Certification: ENERGY STAR certified and AHRI cold-climate designated. Refrigerant: current low-GWP R-454B. Minimum heating ambient: -22 F.
Strengths
- 17,500 BTU certified at 5F, above its own 47F rating.
- AHRI cold-climate designated and ENERGY STAR certified.
- Low-GWP R-454B and the backing of a global HVAC manufacturer.
Weaknesses
- 22.2 SEER2 is the softest in the Extreme Heat group, so cooling-season efficiency is average.
- Its cold-climate tuning is wasted anywhere winters are mild; it needs real cold to shine.
Climate suitability
- Minimum heating ambient
- -22 F[1]
- Certified heating at 5F
- 17,500 BTU/h[2]
- Rated heating at 17F
- 16,600 BTU/h[2]
- Rated heating at 47F
- 15,400 BTU/h[2]
Specifications
ShowHide
- Manufacturer
- Midea
- Brand
- Midea
- Product line
- Midea Easy Pro Extreme Heat
- Model number
- MSEHU-H15B-2A indoor / MO1HS-H15B-2A outdoor
- Indoor unit model
- MSEHU-H15B-2A
- Outdoor unit model
- MO1HS-H15B-2A
- Number of zones
- 1
- Max indoor units
- not published
- Rated cooling capacity
- 15,400 BTU/h[2]
- Rated heating capacity
- 15,400 BTU/h[2]
- Voltage
- 230 V[1]
- MCA
- Not published for this model
- Maximum fuse or breaker size
- Not published for this model
- Breaker needed
- not published
- SEER2
- 22.2 SEER2[2]
- EER2
- 13.5 EER2[2]
- HSPF2 (Region 4)
- 11.5 HSPF2[2]
- HSPF2 (Region 5)
- not published
- COP
- not published
- COP at 47F
- not published
- COP at 5F
- 1.83 COP[2]
- Minimum outdoor heating temperature
- -22 F[1]
- Minimum outdoor cooling temperature
- -13 F[1]
- Maximum outdoor temperature
- 122 F[1]
- Indoor noise range
- Not published for this model
- Outdoor noise rating
- 53 dBA[1]
- Indoor weight
- Not published for this model
- Outdoor weight
- Not published for this model
- Refrigerant
- R-454B[2]
- Refrigerant charge
- not published
- Manufacturer coverage
- not published
- Line-set size
- Not published for this model liquid / Not published for this model suction
- Included line-set length
- Professional installations use separately selected line sets
- Maximum line-set length
- 213 ft[1]
- Max line set per indoor
- not published
- Maximum elevation difference
- Not published for this model
- Max height between indoor units
- not published
- Wi-Fi support
- supported[1]
- Energy Star status
- ENERGY STAR certified[3]
- AHRI certification number
- 218425824[2]
- Warranty
- Base: 5 yr parts / 7 yr compressor (base coverage); Registered: 12 yr parts / 12 yr compressor (online registration at mideacomfort.us within 60 days of installation). Score uses Registered.. 12-year extended warranty listed for Midea single-zone systems; terms apply
- Install path
- Professional install
- Retail price
- Installed quote only
- Available retailers
- not published
- Manual links
- ENERGY STAR exact check 218425824, Easy Pro Extreme Heat installation documentation listing, Easy Pro Extreme Heat high-wall indoor product page, Midea Single-Zone Extreme Heat Pump, AHRI Appendix M1 public detail 218425824
- Specification sheet
- AHRI Appendix M1 public detail 218425824
- Last sourced date
- Jul 27, 2026
Electrical requirements
ShowHide
- Voltage
- 230 V[1]
- Voltage range
- 208/230V[1]
- Phase
- 1[1]
- Frequency
- 60 Hz[1]
- MCA
- Not published for this model
- Breaker needed
- not published
- Maximum breaker size
- Not published for this model
- Maximum fuse size
- Not published for this model
- Maximum cooling current
- not published
- Maximum heating current
- not published
- Manufacturer wire notes
- not published
Installation considerations
ShowHide
- Liquid line
- Not published for this model
- Suction line
- Not published for this model
- Line connection type
- not published
- Precharged length
- not published
- Included line-set length
- Professional installations use separately selected line sets
- Maximum line-set length
- 213 ft[1]
- Max line set per indoor
- not published
- Max height between indoor units
- not published
- Indoor dimensions
- Not published for this model
- Outdoor dimensions
- Not published for this model
- Indoor weight
- Not published for this model
- Outdoor weight
- Not published for this model
- Drain size
- not published
