TOSOT / Multi Ultra Heat
TOSOT Multi Ultra Heat 55k R-32 208/230V 6-Zone Mini-Split
The TOSOT Multi Ultra Heat 6-zone is the top of the line: up to six rooms from one 208/230V outdoor unit on R-32, ENERGY STAR certified, at a certified nominal SEER2 of 21 (EER2 11.65, HSPF2 10). Unlike the smaller Multi Ultra Heat units, the 6-zone is not AHRI cold-climate designated, so treat it as broad-coverage rather than a hard-freeze specialist.
Its certified heating is rated 55000 BTU at 47F, 41000 at 17F, and 36400 at 5F, tapering through deep cold. That certified SEER2 is the all-non-ducted nominal and depends on the heads you attach.
TOSOT is a value brand (TOSOT/Gree family) sold on tosot.com, professionally installed and priced by quote.
Refrigerant generation
R-32 - current-generation refrigerant
Need this installed?
Get installation quotes
Image: TOSOT
- Last sourced
- Jul 29, 2026
SplitAtlas score
8.0 / 10
(21.0 SEER2) among >36k systems
(10.0 HSPF2) among >36k systems
(5F certified capacity: 66.2% of the 47F rating; -22 F heating floor) among >36k systems
(10 yr parts / 10 yr compressor) across the catalogue
(3 verified features) across the catalogue
(6 manuals; spec sheet; 14 error-code rows) across the catalogue
Not evaluated
- Installation accessibility — not applicable (professional install)N/A
professional install - DIY-accessibility not applicable
- Price-to-value — not evaluatedN/A
This is a professionally installed, quote-only system, so we can't score its price. Get an installed quote to compare real cost.
Get a quote
Key ratings
Buyer review snapshot
Best for / skip if
Best for
- 6-zone projects in the 54k outdoor capacity class.
Install difficulty
- Electrical: 230V; MCA 37.5 A; breaker/fuse 40 A.
- Line set: connection type not sourced; precharged 197 ft; max 394 ft.
- 6-zone condenser; indoor-head matching and branch layout are part of the job.
Availability and price context
This TOSOT/Cosmo multi-zone system is sold through dealers, so its price comes as an installed quote that depends on your home. Get installation quotes to price it.
Source date
- Model data sourced
- Jul 29, 2026
- Page reviewed
- Jul 29, 2026
- Source-backed records
- 5
- Newest source retrieved
- Jul 29, 2026
Warranty tiers
- Base
- 10 yr parts / 10 yr compressor - equipment sold and installed by licensed professionals in residential applications
The score uses Base. Additional published terms are shown for reference and not counted in the score.
Model context
- Install path
- This is professional-install equipment; price it with an installed quote.
Strengths
- Six zones of coverage and 55000 BTU of 47F heating from a single outdoor unit.
- ENERGY STAR certified on current R-32 refrigerant at a value price.
- One 208/230V circuit for up to six rooms.
Weaknesses
- Not AHRI cold-climate designated, and heating tapers to 36400 BTU at 5F - size for deep cold carefully.
- Six-zone total capacity is shared and modest per room; size heads carefully.
Climate suitability
- Minimum heating ambient
- -22 F[1]
- Certified heating at 5F
- 36,400 BTU/hNon-Ducted Indoor Units[2]
- Rated heating at 17F
- 41,000 BTU/hNon-Ducted Indoor Units[2]
- Rated heating at 47F
- 55,000 BTU/hNon-Ducted Indoor Units[2]
Specifications
ShowHide
- Manufacturer
- TOSOT
- Brand
- TOSOT
- Product line
- Multi Ultra Heat
- Model number
- TMH60D32MO
- Indoor unit model
- Depends on the indoor units you choose
- Outdoor unit model
- TMH60D32MO
- Number of zones
- 6
- Max indoor units
- 6 units[1]
- Rated cooling capacity
- 55,000 BTU/hNon-Ducted Indoor Units[2]
- Rated heating capacity
- 55,000 BTU/hNon-Ducted Indoor Units[2]
- Voltage
- 230 V[1]
- MCA
- 37.5 A[1]
- Maximum fuse or breaker size
- 40 A[1]
- Breaker needed
- not published
- SEER2
- 21 SEER2Non-Ducted Indoor Units[2]
- EER2
- 11.65 EER2Non-Ducted Indoor Units[2]
- HSPF2 (Region 4)
- 10 HSPF2Non-Ducted Indoor Units[2]
- HSPF2 (Region 5)
- Varies by indoor-unit combination
- COP
- not published
- COP at 47F
- not published
- COP at 5F
- 1.9 COPNon-Ducted Indoor Units[2]
- Minimum outdoor heating temperature
- -22 F[1]
- Minimum outdoor cooling temperature
- -22 F[1]
- Maximum outdoor temperature
- 118 F[1]
- Indoor noise range
- Depends on the indoor units you choose
- Outdoor noise rating
- 54 dBA[1]
- Indoor weight
- Depends on the indoor units you choose
- Outdoor weight
- 225 lb[1]
- Refrigerant
- R-32[2]
- Refrigerant charge
- 112.88 oz[1]
- Manufacturer coverage
- not published
- Line-set size
- 1/4 in ports A-E; allowable indoor units 1-6 liquid / 1/2 in x 2 and 3/8 in x 3; allowable indoor units 1-6 suction
- Included line-set length
- Depends on the indoor units you choose
- Maximum line-set length
- 394 ft[1]
- Max line set per indoor
- 82 ft[1]
- Maximum elevation difference
- 82 ft[1]
- Max height between indoor units
- 82 ft[1]
- Wi-Fi support
- Depends on the indoor units you choose
- Energy Star status
- ENERGY STAR certified[3]
- AHRI certification number
- 217994526Non-Ducted Indoor Units[2]
- Warranty
- Base: 10 yr parts / 10 yr compressor (equipment sold and installed by licensed professionals in residential applications). Score uses Base.. TOSOT warranty information lists a standard 10-year compressor warranty and 10-year parts warranty for equipment sold and installed by licensed professionals in residential applications.
- Install path
- Professional install
- Retail price
- Installed quote only
- Available retailers
- not published
- Manual links
- AHRI public detail 217994526, ENERGY STAR exact AHRI rows 217994526, TOSOT Multi Ultra Heat / TMH60D32MO current product page, TMH60D32MO TOSOT Multi Ultra Heat submittal, TOSOT warranty information
- Specification sheet
- TMH60D32MO TOSOT Multi Ultra Heat submittal
- Last sourced date
- Jul 29, 2026
Installation considerations
ShowHide
- Liquid line
- 1/4 in ports A-E; allowable indoor units 1-6[1]
- Suction line
- 1/2 in x 2 and 3/8 in x 3; allowable indoor units 1-6[1]
- Line connection type
- not published
- Precharged length
- 197 ft[1]
- Included line-set length
- Depends on the indoor units you choose
- Maximum line-set length
- 394 ft[1]
- Max line set per indoor
- 82 ft[1]
- Max height between indoor units
- 82 ft[1]
- Indoor dimensions
- Depends on the indoor units you choose
- Outdoor dimensions
- 38-55/64 x 16-7/32 x 49-49/64 in[1]
- Indoor weight
- Depends on the indoor units you choose
- Outdoor weight
- 225 lb[1]
- Drain size
- not published
